If you follow each subject until the event occurs (the event is usually death, but survival curves can track time until any onetime event), then the curve will eventually reach 0. At the time (X value) when the last subject dies, the percent survival is zero.
If all subjects are followed for the same amount of time, the situation is easy. If one third of the subjects are still alive at the end of the study, then the percent survival on the survival curve will be 33.3%.
If the data for any subjects are censored, the bottom point on the survival curve will not equal the fraction of subjects that survived.
Prior to censoring, a subject contributes to the fractional survival value. Afterward, she or he doesn't affect the calculations. At any given time, the fractional (or percent) survival value is the proportion of subjects followed that long who have survived.
Subjects whose data are censored either because they left the study, or because the study endedcan't contribute any information beyond the time of censoring. You don't know whether or not they would have died after the time of censoring (or do know, but can't use the information because the experimental protocol was no longer being followed). So if any subjects are censored before the last time shown on the survival curve's Xaxis, the final survival percentage shown on the survival graph will not correspond to the actual fraction of the subjects who survived. That simple survival percentage that you can easily compute by hand is not meaningful, because not all the subjects were not followed for the same amount of time.
If the survival curve goes all the way down to 0% survival, that does not mean that every subject in the study died. Some may have censored data at earlier time points (either because they left the study, or because the study ended while they were alive). The survival percentage will drop to zero when the event at the last time point is a death (or whatever outcome you track) and not a censoring. If your data are sorted by X value (which Prism can do using Edit..Sort), the curve will descend to 0% survival if the last Y value is 1 (death), and will end above 0% if the last Y value is 0 (censored).
In the example below, four of the ten subjects die. But the survival curve descends to zero, not to 60%. Why? Because six subjects were censored between 1 and 27 months. We have no idea what would have happened had they stayed in the study until month 28. Since we don't know if they would have lived or died, their data simply doesn't count after the time of censoring (but definitely counts before that). At time 27, only one subject is still being followed, and she or he died at month 28, dropping the percent survival down to zero.
